Thermal Jet® · M-series

Mesh Belt IQF Freezer

Name: Mesh Belt IQF Freezer – Thermal Jet® · M-series
Brand: GLORY

Maximum product yield. High-efficiency impingement freezing.

Proprietary impingement airflow freezes products rapidly while preserving texture, nutrition, taste, colour and yield. The highly permeable belt enables efficient 360° airflow, and the integrated automatic Cleaning-in-Place (CIP) system minimizes cleaning time and supports continuous production. The M-series is the core of the GLORY fully synchronized freezing line, together with glazer, re-freezer and conveyors.

500–1,800

kg/h

> 20 h

without defrost

–45 °C

Te design

Request a quote Datasheet (PDF)

360° airflow

High-velocity air surrounds products from every direction for fast, uniform core freezing.

Quality preservation

Rapid crust freezing minimizes dehydration to maintain texture, appearance and yield.

Flexible capacity

Single and twin-line configurations for different production capacities.

Automatic CIP

Integrated cleaning delivers fast sanitation with minimal manual intervention.

Typical applications

What the Thermal Jet® · M-series freezes

Ideal for seafood, poultry, meat, vegetables, fruits and prepared foods.

Individual shrimp

Tempura shrimp

Langoustine in box

Packed salmon loin

Technical data

Technical specifications

Description	M500	M750	M900	M750V	M900V	M1800T
Nominal freezing capacity (kg/h) ¹	500	750	900	750	900	1,800
Refrigeration at Te ≈ –45 °C (kW)	95	140	170	135	160	320
Freezer configuration	Single-line	Single-line	Single-line	Single-line	Single-line	Dual-line
Belt type	SUS 304 Eyelink or mesh belt
Length (mm)	7,600	10,300	12,100	10,300	11,200	12,100
Belt width (mm)	1000 · 1200 · 1500 · 1800
Height (mm)	3,330
Continuous uptime without defrost	> 20 h
