Contact Plate Freezer
Monolithic cabinet construction with no joints.
The CF-series freezes products in blocks by direct contact heat transfer between aluminium plate surfaces with a high heat-transfer coefficient. High-density polyurethane foam is enclosed in stainless steel sheets that are 100% sealed by welding instead of riveting. The chamber is watertight and resists rust and thermal loss, and a hot-gas defrost function speeds up defrosting.
Fast contact freezing
Aluminium plates transfer heat directly for rapid block freezing.
Welded stainless cabinet
100% sealed by welding instead of rivets: watertight and rust-resistant.
Higher hygiene
No rivets and no leak paths reduce corrosion risk.
Hot-gas defrost
Faster defrosting for more production time.
What the CF-series freezes
For block-frozen shrimp, fish, octopus, squid and other products.
Shrimp block
Fish block
Octopus block
Squid block
Technical specifications
| Description | CF500 | CF750 | CF1000 | CF1500 |
|---|---|---|---|---|
| Nominal freezing capacity (kg/h) ¹ | 500 | 750 | 1,000 | 1,500 |
| Refrigeration at Te ≈ –40 °C (kW) | 45 | 65 | 80 | 120 |
| Number of aluminium plates | 7 | 10 | 11 | 16 |
| Height (mm) | 1,400 | 1,850 | 1,990 | 2,500 |
¹ Nominal capacity basis: Variable products, core inlet/outlet +10 °C / –20 °C. Parameters subject to change without prior notice.
Not sure which size fits your plant?
Tell us your product, size and capacity. A GLORY engineer replies within one working day.
Talk to an engineer
